Home > Products > RFID Series> Passive RFID Reader > UHF RFID Robot Reader

UHF RFID Robot Reader

Model:
WS-RFIDBY
WS-RFIDBY-Laser

UHF RFID Robot Reader complies with EPC Class 1 GEN2,ISO18000-6C and IS18000-6A/B, Driverless car, Airport automated baggage sorting, mechanical equipment with automatic reader, Automatic production line, vehicle like MRT, autocar, UHF RFID reader for floor tag or the equipment reads the module, the additional options of main tool : measuring-distance laser, the longest distance available: 10M (max); reading general RFID tag, the distance available:5M. For the data transmitting, receiving and writing the tag, RFID handheld reader able to connect smart phone, PC and Notebook via bluetooth or WiFi. Installing application on your smartphone and seized by the phone holder, the smart phone will then become an Independent operating management system for the tag, it substantially increases the efficiency. Exclusive two-stage switch, 1st stage for long reading range, 2nd for short reading range, it improves on the time of searching subject, more faster and efficiency.

RFID|Wireless Modules|RF Module|Wireless VIDEO


INTERFACE

Specification

   MetInfo enterprise content manager system | MetInfo CMS  RFID|Wireless Modules|RF Module|Wireless VIDEO  MetInfo enterprise content manager system | MetInfo CMS  MetInfo enterprise content manager system | MetInfo CMS

(Choose one)


APPEARANCE

External Appearance

Standard type

MetInfo enterprise content manager system | MetInfo CMS

Laser type

MetInfo enterprise content manager system | MetInfo CMS


FEATURES

Application

RFID|Wireless Modules|RF Module|Wireless VIDEO

RFID|Wireless Modules|RF Module|Wireless VIDEO

RFID|Wireless Modules|RF Module|Wireless VIDEO

RFID|Wireless Modules|RF Module|Wireless VIDEO

MetInfo enterprise content manager system | MetInfo CMS

MetInfo enterprise content manager system | MetInfo CMS

RFID|Wireless Modules|RF Module|Wireless VIDEO


Video tutorial

RFID|Wireless Modules|RF Module|Wireless VIDEO

https://www.youtube.com/watch?v=U6ThTLl4VD0&feature=youtu.be



SPECIFICATION

Technical specifications

Working Frequency:902~928MHz

Protocol:EPC Class 1 Gen 2 ISO18000-6C IS18000-6A/B

Antenna:circular polarized antenna (RHCP)

Reading distance:5m

RF Power:23~30dBm

Interface:RJ45 / RS-232 / RS-485 / WiFi (Choose one)

Adaptor:12V~24V

Working temperature:-20°C~+80°C

Storage temperature:-10°C~+80°C

Humidity:20%~95%(non-condensing)

Size:75.15x58.35x25mm
