Millimeter-Wave Radar Sensor
model: WS-RADAR62GBY
The WS-RADAR62GBY is an innovative 62GHz millimeter-wave industrial radar sensor launched by WENSHING Electronics, specifically designed for modern industrial automation and smart manufacturing environments. This product utilizes state-of-the-art millimeter-wave radar technology to provide extremely high-precision distance measurement capabilities, achieving an outstanding measurement error of ≤1 cm.
Compared to traditional photoelectric switches, this sensor boasts superior environmental adaptability and anti-interference capabilities. It offers a maximum detection range of up to 25 meters, coupled with low latency and low power consumption, making it perfectly suited for various industrial and commercial application scenarios. Whether in harsh factory environments or precise automated production lines, the WS-RADAR62GBY delivers stable and reliable sensing performance.
The product design considers actual application needs, integrating a relay output function that can directly drive loads or connect to control systems, significantly simplifying system integration complexity and providing an ideal sensing solution for the Industry 4.0 era.
Product Series & Accessories
Comprehensive Product Portfolio
The WS-RADAR62GBY offers a comprehensive range of product series and accessory options to meet diverse application requirements. The standard package includes the sensor unit, mounting bracket, connecting cables, and a detailed user manual.
We provide various mounting accessories, including adjustable angle brackets, protective enclosures, extension cables, and more, ensuring stable operation in all environments. All accessories undergo rigorous testing to guarantee perfect compatibility with the main unit.
Standard Accessories
  • 62GHz Radar Sensor Unit
  • Standard Mounting Bracket
  • Power Connection Cable
  • Relay Output Cable
  • Mounting Screw Set
Optional Accessories
  • Adjustable Angle Universal Bracket
  • Outdoor Protective Enclosure (IP67)
  • Extension Cables (1m/3m/5m)
  • DIN Rail Mounting Base
  • Dedicated Calibration Tool
Technical Support
  • Traditional Chinese User Manual
  • Installation Tutorial Videos
  • Configuration Software Tools
  • Technical Support Documentation
  • Regular Firmware Updates
Core Technical Specifications
Detection Range
0.13 m ~ 25 m
Flexible ranging capability suitable for various application scenarios
Ultra-High Precision
Distance Accuracy ±1 cm
Angle Accuracy < ±1°
Response Time < 40 ms
Operating Frequency
62 GHz
Frequency Band: 56–62 GHz
Millimeter-wave Radar Technology
Power Specification
6V ~ 28V DC
Relay Output 1A
Low Power Consumption Design
Physical Dimensions
Product Dimensions (mm): 58.7 × 75 × 25
Compact design, easy for installation and integration
Key Features
  • High-precision ranging and angle detection
  • Long-range detection capability up to 25m
  • Excellent anti-interference performance
  • Ultra-low power operation
  • Fast response time < 40ms
  • Supports flexible distance settings
Smart Parking Lot Applications
Parking Space Detection System
The WS-RADAR62GBY excels in smart parking lot management systems. The sensor accurately detects parking space occupancy status and reports it to the parking management system in real-time, helping drivers quickly find available spaces.
Compared to traditional geomagnetic or infrared sensors, millimeter-wave radar is unaffected by light or dust, ensuring stable operation in both outdoor and underground parking lots. Its 25-meter detection range can cover multiple parking spaces, reducing equipment quantity and installation costs.
01
Real-time Parking Space Detection
Millimeter-wave radar continuously scans parking areas to accurately determine vehicle entry and exit status.
02
Real-time Data Transmission
Immediately reports parking space occupancy information to the management system via relay or digital interface.
03
Smart Guidance Instructions
Integrates with LED displays or mobile apps to guide drivers to available spaces.
04
Data Analysis and Optimization
Accumulates usage data to analyze parking lot patterns and optimize management strategies.
Industrial Automation Applications
Material Height Measurement
Accurately measures the height of material piles, liquid levels, or stacked products, ensuring smooth production processes and precise inventory management. The ±1cm accuracy meets stringent quality control requirements.
Conveyor Belt Object Detection
Detects object position and distance in high-speed conveyor belt systems, combined with a fast 40ms response time, achieving precise material sorting and positioning control.
Machine Vision Assistance
Provides precise distance information in conjunction with machine vision systems, assisting robotic arms with precision assembly, welding, or inspection tasks, enhancing automation levels.
Advantages of Automation Equipment Integration
  • Non-contact measurement, no wear-and-tear consumables
  • Unaffected by dust, smoke, or steam
  • Wide operating temperature range
  • Strong anti-electromagnetic interference capability
  • Excellent long-term stability
  • Low maintenance costs
Security Gate Control Applications
Smart Access and Gate Control
The WS-RADAR62GBY is an ideal sensing solution for gate control. Compared to traditional infrared or microwave sensors, millimeter-wave radar offers more precise detection capabilities and a lower false trigger rate.
The sensor accurately detects the approach distance and direction of personnel, enabling intelligent door opening logic. For example, the door opens when someone approaches from the inside but remains closed when someone passes by from the outside, effectively saving energy and enhancing safety. It delivers excellent performance in scenarios such as factory gates, warehouse rolling doors, and commercial building revolving doors.
Its 25-meter detection range provides ample time for the system to pre-activate the door mechanism, ensuring smooth pedestrian traffic. The fast response time prevents the risk of door-related injuries, and with relay output, it can directly control door mechanisms or integrate with existing access control systems.
Human Approach Detection
Accurately detects human distance and movement direction
Smart Door Opening Logic
Determines whether to activate the door mechanism based on detection data
Safety Anti-Pinch Protection
Continuously monitors the door area to prevent pinching accidents
Energy-Saving Operation Mode
Reduces unnecessary door openings, lowering energy consumption
Installation and Usage Guide
Installation Method Selection
It is recommended to install horizontally or vertically, ensuring the sensor faces the detection area. Use standard brackets or DIN Rail mounting bases, fixed to a stable structure. Installation height depends on the application, usually 1-3 meters from the target area is optimal.
Detection Distance Adjustment
The detection distance must be set within the effective range of 0.13 m to 25 m. Use dedicated setting software or built-in buttons to adjust the distance threshold. It is recommended to perform on-site testing first to confirm the optimal detection parameters before finalizing the settings.
Environmental Considerations
Avoid installation near large metal objects or strong electromagnetic equipment to prevent interference or reflections. Although the sensor has anti-interference capabilities, a good installation environment can still improve performance stability and service life.
Outdoor Protection Measures
For outdoor environments, it is recommended to install an IP67 protective cover to shield the sensor from rain and dust. Regularly clean the sensor surface to ensure radar waves are unobstructed. For extreme temperature environments, evaluate whether additional temperature control measures are needed.

Important Reminder
For first-time installation, it is recommended to have professional technical personnel perform the task and carefully read the user manual. If you have any questions, please contact Wenxing Electronics Technical Support Team; we provide comprehensive installation guidance and online technical consulting services.
System Integration Solutions
The WS-RADAR62GBY is designed with comprehensive consideration for system integration requirements, offering diverse interface and communication protocol support. The sensor can be easily integrated into existing industrial automation systems, smart building management platforms, or IoT applications, providing strong assistance for enterprise digital transformation.
PLC Controller Integration
Through relay outputs or digital I/O interfaces, direct connection to various brands of PLC systems (Siemens, Mitsubishi, Omron, etc.) is achieved, enabling integration of factory automation control logic.
IoT Platform Connectivity
Supports mainstream IoT communication protocols, allowing connection to cloud platforms such as MQTT and HTTP API, enabling remote monitoring, data analysis, and predictive maintenance functions.
Access Control System Integration
Seamlessly integrates with access controllers and gate drivers, providing intelligent access control. Supports various door control protocols, adaptable to a wide range of automatic doors and security systems.
Warehouse Management System
Integrates with WMS (Warehouse Management System) and ERP systems to provide real-time inventory height and material location information, optimizing warehouse space utilization and logistics efficiency.
Parking Management Platform
Connects to parking management systems to provide real-time parking space information, automatic billing, and parking guidance functions. Supports integration with mobile apps and LED display systems.
Mechanical Automation Equipment
Coordinates with robot control systems, CNC machine tools, and automated production lines to provide precise position feedback and safety protection functions, enhancing production efficiency and personnel safety.
Technical Support and Customization Services
We provide comprehensive technical support services, including system architecture planning, communication protocol customization, and firmware function adjustments. Whether for small projects or large-scale deployments, our technical team offers professional advice and integration support.
